Manufacturer: Technics
Model: RS-671 USD
Type: Single deck
Years of manufacture: c. 1976
Made in: Japan
Color: silver, black
Remote control: no
Power consumption: 20 W
Dimensions: 410 x 140 x 330 mm
Weight: 9.4 kg
Original price approx.: 1'200 DM

Connections

Number of inputs:
Line In (DIN): 60 mV / 68 kOhm.
Microphone: 0,3 mV / 600 - 20.000 Ohm
Number of outputs:
Line Out (DIN): 0.42 V / 50 kOhm
Headphones (6.3mm jack): 65 mV / 8 Ohm

Technical Data

Audio heads:
1x HPF sound head (recording, playback).
1x ferrite head (erase)
motors:
1x electronically controlled (tone shaft/capstan).
1x DC (tape platter)
Synchronous fluctuations: 0.063% (WRMS), ±0.15% (DIN)
Band types: type I (normal band), type II (CrO2).
Frequency response:
Type I:
DIN: 25 - 14,000 Hz
±3 dB: 30 - 13,000 Hz
Type II:

DIN: 25 - 15,000 Hz
±3 dB: 30 - 14,000 Hz
Distortion Ratio:
Signal-to-noise ratio:
Signal-to-noise ratio: 52 dB (Normal), 62 dB (Dolby, above 10 kHz).
Auto reverse: no
Title search: no
Dolby: yes
MPX filter: no
Fader: no
Pitch control: no
CD synchro recording: no

Special Features

Analog level meter

Remarks
Other models in the same series:
Technics RS-615 US
Technics RS-630 T US
Technics RS-671 USD
