Details
Specifications
Model designator (SF)
Ultimate
Wheel size
700c
Travel (mm)
40mm
Damper Type
Charger Race Day 2
Fork offset
45mm (700c)
Maxle included
Maxle Ultimate
Color (FS)
Gloss Black
E-Bike Approved
E-bike Approved
Steerer
1.5" Tapered
Axle
12x100mm
Axle to Crown (mm)
435
Brake type (FD)
Direct Flat Mount Disc
Crown Material
Forged, hollow aluminum
Upper crown type
n/a
Lower leg type
Magnesium
Upper Tube Finish
Fast Black
Upper tube type
30mm straight wall aluminum
Damper adjust
Crown
Damping adjustments
Extl rebnd, 2 pos comp (open/lock)
Volume reducer
n/a
Spring
Solo Air
Spring rate
n/a
Max Tire Diameter (mm)
716
Max Tire Width (mm)
50
Maximum Rotor Size
180mm
Minimum Rotor Size
160mm
Fender Compatibility
Bolt On - Full or Short
Crown OD (mm)
56
Max recommended system weight
331lbs/150kg
Max Air Pressure (PSI)
200
