Używany Intel NUC 5 z dyskiem SSD i pamięcią RAM typu DDR3. Doskonały wybór dla osób poszukujących kompaktowego komputera stacjonarnego o wysokiej wydajności.

Essentials
Download Specifications
Product Collection
Intel® NUC Kit with 5th Generation Intel® Core™ Processors
Code Name
Products formerly Rock Canyon
Processor Included
Intel® Core™ i3-5010U Processor (3M Cache, 2.10 GHz)
Board Number
NUC5i3RYB
Supported Operating Systems
Windows 10, 32-bit*, Windows 10, 64-bit*, Windows 8.1, 32-bit*, Windows 8.1, 64-bit*, Windows 7, 32-bit*, Windows 7, 64-bit*
Supplemental Information
Marketing Status
Discontinued
Launch Date
Q1'15
Warranty Period
3 yrs
Embedded Options Available
No
CPU Specifications
Total Cores
2
Total Threads
4
Processor Base Frequency
2.10 GHz
Memory & Storage
Max Memory Size (dependent on memory type)
16 GB
# of Memory Slots
2
Memory Types
DDR3L-1333/1600 1.35V SO-DIMM
Max # of Memory Channels
2
Max Memory Bandwidth
25.6 GB/s
ECC Memory Supported ‡
No
Internal Drive Form Factor
M.2 and 2.5" Drive
# of Internal Drives Supported
2
M.2 Card Slot (storage)
22x42/60/80
I/O Specifications
Graphics Output
Mini-DP 1.2; Mini-HDMI 1.4a
# of Displays Supported ‡
3
# of USB Ports
6
USB Configuration
2x front and 2x rear USB 3.0; 2x USB 2.0 via internal headers
USB Revision
2.0, 3.0
USB 2.0 Configuration (External + Internal)
0 + 2
USB 3.0 Configuration (External + Internal)
2B 2F + 0
Total # of SATA Ports
2
Max # of SATA 6.0 Gb/s Ports
2
RAID Configuration
2.5" HDD/SSD + M.2 SATA/PCIe SSD (RAID-0 RAID-1)
Audio (back channel + front channel)
7.1 digital (mHDMI mDP); L+R+mic (F)
Integrated LAN
Intel® Ethernet Connection I218-V
Wireless Included
Intel® Dual Band Wireless-AC 7265
Bluetooth Version
4.2
Consumer Infrared Rx Sensor
Yes
Additional Headers
2x USB2.0, AUX_PWR
Expansion Options
PCI Express Revision
Gen2
PCI Express Configurations ‡
M.2 slot with PCIe x4 lanes
Package Specifications
TDP
15 W
DC Input Voltage Supported
12-19 VDC
Chassis Dimensions
115 x 111 x 49mm
Board Form Factor
UCFF (4" x 4")
Advanced Technologies
Intel® HD Audio Technology
Yes
Intel® Rapid Storage Technology
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes
Intel® Virtualization Technology (VT-x) ‡
Yes
Security & Reliability
Intel® Platform Trust Technology (Intel® PTT)
Yes
TPM
No
Intel® AES New Instructions
Yes
