Dekoder Tuner STi 7101 HD
- Linux®, Windows® CE and OS21 compatible ST40 CPU core: 266 MHz
- Transport filtering and descrambling
- Video decoder: H.264 (MPEG-4 part 10) and MPEG-2
- SVP compliant
- Windows Media™ DRM support
- Graphics engine and dual display: standard and high-definition
- Audio decoder: including Windows Media™ Audio 9 (WMA-9) and WMA-9 Pro
- DVD data retrieval and decryption

Embedded interfaces
- USB 2.0 host controller/PHY interface
- DVI/HDMI™ output
- Digital audio and video auxiliary inputs
- Low-cost modem
- 100BT Ethernet controller with integrated MAC and MII/RMII interface for external PHY
- Serial ATA (SATA)

Processor subsystem
ST40 32-bit superscaler RISC CPU
– 266 MHz, 2-way set associative 16 Kbyte ICache, 32 Kbyte DCache, MMU
– Five-stage pipeline, delayed branch support
– Floating point unit, matrix operation support
– Debug port, interrupt controller

Transport subsystem
TS merger/router
– Two serial/parallel inputs
– One bidirectional interface
– Merging of three external transport streams
– Transport streams from memory support
– NRSS-A module interface
– TS routing for DVB-CI and CableCARD™ modules
